Self-service Kiosk - 24inch
In stock
Our wall-mounted, interactive Self Checkout Kiosks help you drive sales, reduce operational costs, and improve speed of service at your hospitality venue.
Self service kiosks allow your customers to order and pay themselves, while the full integration with Grafterr Hospitality software suite puts you in full control of the experience they see - included customisation options allow you to easily adjust the images, designs and even button colours to match your existing branding.
Powerful reporting and payment solutions built-in
With the power of the included ePOS software suite at its core, your kiosk can seamlessly synchronise your existing POS food menus, send orders directly to the kitchen for preparation, instantly process card payments, scan gift vouchers, and even promote and up-sell additional items for an average increase in order size of up to 20%.
The included reporting suite provides an in-depth insight into your best selling items and customer orders, while all other business-crucial data is only a few clicks away inside the cloud back-office.
Checkout Kiosk Mini package features:
- Self-service kiosk with a 24 inch HD touchscreen and Wi-Fi/LAN connectivity
- Full integration with our ePOS software that lets you gain powerful insights into your customers and sales
- A sleek, space-saving design perfect for smaller hospitality venues
- Fully customisable checkout experience allows customers to choose between eat-in or take away orders, cash or card payments, apply gift vouchers and more
- Simple ordering and payment interface that lets customers order & pay on their own
- Built-in automatic upselling of additional items, increasing average order size by up to 20%
- An integrated customer receipt printer and voucher/QR code scanner
Included in the box:
- 24" touch screen self checkout kiosk
- Metal bracket for wall mounting
- All cables required for installation
RTC real - time clock : | Support |
2-D: : | PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec, Hanxin, etc. |
1-D: : | UPC, EAN, Code128, Code 39, Code 93, Code11, Matrix 2 of 5, Interleaved 2 of 5, Codabar, MSI Plessey, GS1 DataBar, China Postal, Korean Postal, etc. |
Print Contrast : | 25% minimum reflective difference |
Interfaces Supported : | USB, RS232 |
Motion Tolerances : | up to 600cm per second |
Roll/Pitch/Yaw : | 360°, ±65°, ±60° |
Field of View : | 50° (H) x 35° (V) |
Driver : | Windows98/2000/NT/XP/VISTA/WIN7/WIN8/LINUX |
Scanner Light Source : | Illumination: 617nm RED LED |
Auto cutter method : | Automatic paper cutting function |
Power Supply : | DC24V, 2A |
Emulation : | ESC/POS |
Printing Resolution : | 8 dots/mm,576 dots/line |
Paper Width : | 80mm |
Printing Speed : | 170 mm/s |
Printing Method : | Thermal Line printing |
Image Format Support : | Supports: BMP, JPEG, PNG, GIF |
Video Format Support : | Supports: wmv, avi, rm, rmvb, mpeg, ts, mp4 |
Time - power - off : | Support |
Ethernet : | 1@, 100M/1000M Ethernet |
WIFI, BT : | Built in WIFI, BT4.0(optional) support dual frequency WIFI, dual antenna |
3G/4G (optional) : | Built in WCDMA, EVDO, 4G Full Netcom, Supports voice calls |
HDMI Output : | 1@support 1080P@60Hz,4kx2k@60Hz output |
USB Interface : | 6 insert pin, 2 standard USB interface |
Serial Port : | 5 channels serial port (3*232;1*TTL;1*485) |
ROM : | 16GB |
RAM : | 4GB |
CPU : | Rockchip RK3399 higest64 bits CPU,Main Frequency 2.0GHz;1.Big,Little architecture;Dual-core Cortex-A72 + Quad Cortex- A53;2.Built-in low power consumption Mcu Cortex-Mo GPU:Quad Cortex-Mali-T860MP4;Android 7.1 |
Touch Screen Transparency : | 87±2% |
Touch Screen Type : | 10 - point capacitive touch screen |
Screen Resolution : | 1920*1080 |
ResponseTime : | 8ms |
Viewing Angle : | 178/178 |
Screen Contrast Ratio : | 1000:1 |
Screen Brightness : | 250cd/㎡ |
Screen Size : | 24" |
Screen Brand : | BOE |
Minimum Resolution : | 4 mil code 39 |
Speakers : | 8Ω 5W Active loud speaker |
Operating Temperature : | 0 ~ 40℃ (32 ~ 104F) |
Storage Temperature : | 10 ~ 95% @ 40℃ |
Power Input : | AC 100-240V |
Dimensions (W x H x D) : | 37 x 85 x 9.5cm |
Weight : | 19kg |
Installation : | Wall mounted/fix on stand |
